- Wall panel: sandwich style, δ =50mm, polystyrene, rock wool available as required.
- Basement: steel structure, 3 rows of vein board and 2 rows of grids, full grids as optional.
- Door: 3 pcs of front door without aluminum side cover. 1pcs of emergency door with pressure lock.
- Ramp: 2 pcs of vein board.--One7.5kw intake fan and one5.5kw exhaust fan.
- 4m straight exhaust ducts, one 90° bend, and one 60° bend. 5m straight chimney and2 small bends.
- Spraying/baking transition damper, automatically air controlled.
- Heat exchanger: stainless steel. RIELLO G20 burner.
- Automatically stop when preset time is up. Constant temperature spraying.
- Environmental filter: the equipment can be adopted M style activated carbon or drawer style activated carbon as optional.
